Miami Counter Systems are an aluminium sliding window solution designed to provide heightened security and style in interior spaces.
Available in a wide range of finishes, Miami can be customised with speaking holes, a variety of locks, catches and acoustic or weather seals. This system delivers a modern, minimalist aesthetic compared to the traditional bulky design of conventional window frames.
Miami is simple to install throughout a variety of commercial settings and is an increasingly popular design within commercial eateries and reception spaces.
When ordering a Miami Counter Window System, please specify the following:
Opening Height (mm)
Opening Width (mm)
Lockable (Yes / No if required)
Finger Grip Height on glass (mm from base of panel)
Qty required
Q: What is the Miami Counter Window and when are they used?
A: Miami Counter Window Systems are often used in reception areas, serveries and display cabinets. They are used internally and come with a variety of lockable solutions.
Q: Can the tracks and head aluminium extrusion be trenched into existing environment (plaster or cabinetry)?
A: Yes often this is done to create a minimalist look.
Q: What is the maximum panel size for the Miami Counter Window System?
A: Miami 120 – Max Panel size of 1.4m2 / Max 21kg per Panel / Max height 1220mm
Miami 180 – Max Panel size of 3.78m2 / Max 45kg per Panel / Max height 1800mm
Miami 220 - Max Panel size of 3.78m2 / Max 45kg per Panel / Max height 1800mm
Q: What is a finger grip?
A: A ground recess cut into the glass that provides a neat provision to open and close the sliding window.
Q: How Secure are these units once locked?
A: We would only recommend that they are used internally as the locks are relatively light duty.
